Input voltages / CSA 200 – 480 V, 1-PH, 50/60 Hz 200 – 600 V, 3-PH, 50/60 Hz CE 380/400 V, 3-PH, 50/60 Hz |
Input Current @ 9 kW / CSA 200/208/240/480 V, 1-PH, 52/50/44/22 A 200/208/240/480/600 V, 3-PH, 32/31/27/13/13 A |
Output current / 20 - 65 A |
Rated output voltage / 139 VDC |
Duty cycle @ 40°C (104°F) / CSA 50% @ 65 A, 230 – 600 V, 1/3-PH 40% @ 65 A, 200 – 208 V, 1/3-PH 100% @ 46 A, 230 – 600 V, 1/3-PH |
Open circuit voltage (OCV) / CSA 295 VDC |
Weight with 7.6 m (25') torch / CSA 29 kg (64 lbs) CE 26 kg (57 lbs) |
Gas Supply / Clean, dry, oil-free air or nitrogen |
Recommended gas inlet
flow rate / pressure / Cutting: 189 l/min (400 scfh; 6.7 scfm) @ 85 psi (5.9 bar) Gouging: 450 scfh; 212 l/min (7.5 scfm) @ 70 psi (4.8 bar) |
Input power cable length / 3 m (10') |
Power supply type / Inverter - IGBT |
Dimension(L x W x H) / 500 mm (19.7") D; 234 mm (9.2") W;455 mm (17.9") H |
