Input voltages / 120-240 V, 1-PH, 50/60 Hz |
Input current @ 3.8 kW / 120-240 V, 1-PH, 25-18.8 A |
Output current / 15-30 A |
Rated output voltage / 125 VDC |
Duty cycle @ 40°C (104°F) / 35%, 240 V20%, 120 V |
Open circuit voltage (OCV) / 256 VDC |
Weight w/ 4,5 m (15') torch / CSA: 9.7 kg (21.4 lbs)CE, CCC: 9.5 kg (21 lbs) |
Gas Supply / Clean, dry, oil-free air or nitrogen |
Recommended gas inlet
flow rate / pressure / 113.3 l/min (4 scfm) at 5.5 bar (80 psi) |
Input power cable length / 3 m (10') |
Power supply type / Inverter - IGBT |
Engine drive requirement / 5.5 kW for full 30 A output |
Certifications / CSA-certified for use in the Americas and Asia, except China CE, C-Tick, CU/GOST, Ukr, and Serbian — for use in Europe, Australia, Belarus, Kazakhstan, Russia, Serbia, Ukraine, and other countries where accepted. CCC for use in China. |
Warranty / Power supplies have a 3-year warranty and torches a 1-year warranty. |
Recommended gas inletflow rate / pressure
/ 113.3 l/min (4 scfm) at 5.5 bar (80 psi) |
Dimension(L x W x H) / 592 mm D; 274 mm W; 508 mm H (23.3" D; 10.8" W; 20.0" H) |
