Processes / AC/DC Lift TIG (GTAW), HF TIG(GTAW), Stick (MMAW) |
Voltage / 240V, +/- 15%, 15A Plug 50/60Hz |
Generator Requirement / 10kVA |
Current Range (DC TIG) / 5 - 200A |
Current Range (DC Stick) / 5 - 170A |
Duty Cycle (DC TIG) / 200A @ 20%, 18V (40ºC, 10mins) |
Duty Cycle (DC Stick) / 170A @ 15%, 26.8V (40ºC, 10mins) |
Max OCV / 76V DC |
Dimension(L x W x H) / 400H x 240W x 475D mm |
Weight / 22 kg |
