Single phase input / 230 V 50/60 Hz |
Max. installed power / 6,5 KW |
Input Power / 8,7 KVA 25% |
Current range / 25 A / 250 A |
Duty Cycle / 200 A 25% 130 A 60% 100 A 100% (10 min. cycle, 40°C, according to EN60974.1) |
Number of regulation steps / 2 x 6 |
Wire sizes that can be used / Solid 0,6/0,8/1 |
Max. wire spool size / Ø 300 mm/15 Kg |
Protection class IP / 21 C |
Weight / 58,5 Kg |
Dimensions / 542 x 915 x 795 |
